Yutai Jinyuan Machinery Co., Ltd. is a professional manufacturer of grain processing equipment with a 30-year history. Jinyuan Machinery specializes in manufacturing complete sets of rice and Xiaomi processing equipment. Its products cover raw grain cleaning, compound stone removal, hulling, grain rough separation, rice milling, grading, polishing, photoelectric color selection, and weighing and packaging.
-
![Bucket Elevators Are Used]()
Bucket Elevators Are UsedAccording to production capacity, rice processing equipment can be divided into small, medium, and large sizes. The process design and layout of our company's rice processing equipment are mainly...read more -
![Bucket Elevators]()
Bucket ElevatorsA bucket elevator is a continuous conveying machinery that uses a series of hoppers to transport loose materials vertically or near vertically. It mainly consists of a hopper, a driving device,...read more -
![20 Tons Bucket Elevators]()
20 Tons Bucket ElevatorsAccording to production capacity, rice processing equipment can be divided into small, medium, and large sizes. The process design and layout of our company's rice processing equipment are mainly...read more -
![2 Tons Bucket Elevators]()
2 Tons Bucket ElevatorsThe structure and working principle of a hoist may vary depending on the specific type and application scenario, but the commonality is the use of mechanical force to lift and move objects. This...read more -
![5 Tons Bucket Elevators]()
5 Tons Bucket ElevatorsSmall rice processing machines are suitable for households or small-scale food processing manufacturers, mainly used for processing grain crops such as rice and millet. During the processing, a...read more -
![10 Tons Bucket Elevators]()
10 Tons Bucket ElevatorsThe purpose and advantages of small-scale rice processing equipment: Rice is an indispensable food in daily life and also the staple food that we consume the most in our daily lives. With the...read more -
![30 Tons Bucket Elevators]()
30 Tons Bucket ElevatorsThe rice color sorter is a type of grain sorting machine, which mainly uses spectral technology and image recognition technology to divide the selected rice by color based on the color difference...read more -
![50 Tons Bucket Elevators]()
50 Tons Bucket ElevatorsRice processing machinery has a beautiful appearance and a relatively simple overall structure, making it a better choice for rice processing. This device has the characteristics of reasonable...read more
Why Choose Us
Qualification Certification
We hold patent certificates and have passed ISO9001 international quality management system certification.
R&D Capabilities
We have strong R&D and design capabilities, equipped with a complete and efficient product R&D center, and are committed to technological innovation and product upgrades.
Quality Control
We strictly implement quality control procedures to ensure that each process meets international standards, so as to provide customers with high-quality products and services.
Professional team
Our company has a professional design team with many years of market experience, which has participated in the design, installation, commissioning, and service of multiple complete projects.
Our Best-Selling Elevators
2 Tons Bucket Elevators
The structure and working principle of a hoist may vary depending on the specific type and application scenario, but the commonality is the use of mechanical force to lift and move objects. This article introduces the classification, composition, additional supporting equipment, process, and price of rice processing equipment.
Bucket Elevators
A bucket elevator is a continuous conveying machinery that uses a series of hoppers to transport loose materials vertically or near vertically. It mainly consists of a hopper, a driving device, top and bottom rollers, a traction chain or conveyor belt, and a tensioning device.
20 Tons Bucket Elevators
According to production capacity, rice processing equipment can be divided into small, medium, and large sizes. The process design and layout of our company's rice processing equipment are mainly based on production capacity, raw material characteristics, market demand, and product characteristics for reasonable layout and design, in order to achieve the best use function and purpose.
Our Company Has More Products to Offer, Please Browse the Product Categories on the Website, If You Have Any Needs, Please Contact Us.
Elevators Specification
|
Capacity |
Cubic Ft./hr |
Cubic Meters/hr |
Buckets |
Belting |
|
75 BPH |
94 ft3/hr |
2.7 m3/hr |
3-3/4” x 3” (95 mm x 76 mm) |
4” (102 mm) |
|
200 BPH |
250 ft3/hr |
7 m3/hr |
3-3/4” x 3” (95 mm x 76 mm) |
4” (102 mm) |
|
175 BPH |
220 ft3/hr |
6 m3/hr |
6” x 4” (152 mm x 102 mm) |
6-1/2” (165 mm) |
|
500 BPH |
630 ft3/hr |
17 m3/hr |
6” x 4” (152 mm x 102 mm) |
6-1/2” (165 mm) |
|
640 BPH |
800 ft3/hr |
22 m3/hr |
7” x 4-1/2” (178 mm x 114 mm) |
8” (203 mm) |
|
1,200 BPH |
1,500 ft3/hr |
42 m3/hr |
7” x 4-1/2” (178 mm x 114 mm) |
8” (203 mm) |
|
1,600 BPH |
2,000 ft3/hr |
56 m3/hr |
7” x 4-1/2” (178 mm x 114 mm) |
8” (203 mm) |
|
1,300 BPH |
1,625 ft3/hr |
46 m3/hr |
11” x 5-1/2” (279 mm x 140 mm) |
12” (305 mm) |
|
3,500 BPH |
4,375 ft3/hr |
124 m3/hr |
11” x 5-1/2” (279 mm x 140 mm) |
12” (305 mm) |
|
4,500 BPH |
5,625 ft3/hr |
159 m3/hr |
11” x 5-1/2” (279 mm x 140 mm) |
12” (305 mm) |
|
2,000 BPH |
2,500 ft3/hr |
71 m3/hr |
9” x 5-1/2” (229 mm x 140 mm) |
21” (533 mm) |
|
4,000 BPH |
5,000 ft3/hr |
141 m3/hr |
9” x 5-1/2” (229 mm x 140 mm) |
21” (533 mm) |
|
6,000 BPH |
7,500 ft3/hr |
212 m3/hr |
9” x 5-1/2” (229 mm x 140 mm) |
21” (533 mm) |
|
4,400 BPH |
5,500 ft3/hr |
155 m3/hr |
11” x 7” (279 mm x 178 mm) |
24” (610 mm) |
|
6,000 BPH |
7,500 ft3/hr |
212 m3/hr |
11” x 7” (279 mm x 178 mm) |
24” (610 mm) |
|
8,000 BPH |
10,000 ft3/hr |
283 m3/hr |
11” x 7” (279 mm x 178 mm) |
24” (610 mm) |
● It makes use of energy effectively for material transport rather than air as in the pneumatic system.
● They are compact hence they use less ground space.
● You can avail them for handling different capacity of materials.
● They can handle various types of materials and it behaves gently with it.
● It can handle materials at low temperatures and can manage free-flowing material too.
● One of the main advantages is that it can move materials vertically upwards unlike belt conveyors.
Elevators Structure
The Basic Principle Of Elevators
The working principle of the elevator is relatively simple. When the equipment is working, the material is evenly fed through the feeding port. Rising until it reaches the top of the driving drum, the bucket starts to turn over, and then under the action of centrifugal force or gravity, the material is unloaded from the discharge port and sent to the next process.
When the bucket is filled with materials through the lower feed port, the bucket moves upward along the ascending section as the chain runs. During the ascending process, the materials are affected by centrifugal force and gravity and move upward along the ascending section of the elevator.
When the bucket reaches the top of the elevator, it turns to the descending section under the guidance of the turning wheel.
In the descending section, the bucket runs downward along the chain, and when it reaches the discharge port, the discharge device unloads the materials to the destination, completing a conveying process.
General Safety Considerations for Elevators
Any equipment anomalies should be reported to the proper staff, and all pertinent information should be logged in the device's records. Unusual sounds and smells and excessive wear, damage, or malfunction are signs of irregularities.
Make sure that every guard is installed and in good condition.
Never use machinery with worn, damaged, or broken parts.
Always adhere to the manufacturer's recommended adjustment methods to prevent damage or wear before it is necessary.
Keep track of all adjustments, lubrications, maintenance, and inspections. The records should include the date, materials used, state of each component, and signature of the person who maintained the bucket elevator.
Before any inspection, maintenance, lubrication, or adjustment, turn off, lock out, and tag machine controls.
Proper bucket elevator operation methods must be followed in addition to routine maintenance. As a result, only trained workers should operate bucket elevators.
Select a project - Determine quantity, style and delivery time.
Sign Contract - Provide efficient, high-quality services.
Production - Strict control and quality control at all levels.
Delivery - Delivery to customers according to contract time.
Packaging and Shipping
|
Packaging |
Wooden box, PE film |
|
Transportation methods |
Road transport, rail transport, sea transport, air transport |
Production Equipment
